pg_stat_bgwriter view provides some interesting information about the background writer. This view provides only one row. If you want to analyze these data, these results has to be stored somewhere with a timestamp. The following shall show that it allows an insight into the changes performed in shared buffer cache and also hints for tuning several server parameters.
If a backend process (a client) requests data it is either found in a block in shared buffer cache or the block has to be allocated (read from disk). The latter is counted in
buffers_alloc column. The usage count of this block is increased. The backend process modifies data in this requested page, so this page becomes dirty. With the commit the transaction is written to WAL file. At some moment the background writer will synchronize the dirty page with the disk and mark this page as clean.
This latter asynchronous process can be triggered by the following three events:
- regular checkpoint
- backend request
- background clean process.
The regular checkpoint is triggered either when the number of available
checkpoint_segments are exhausted or when the
checkpoint_timeout is reached. The first are counted in
checkpoints_req column, the latter in
checkpoints_timed column. How many blocks during checkpoint are written is counted in
It may happen that a dirty page is requested by a backend process. In this case the page is synched to disk before the page is returned to the client. The number of those pages are incremented in
It may happen that a new page has to be allocated and for this an allocated page has to be cleared. PostgreSQL may clear pages with a low usage count in advance. The process scans for dirty pages with a low usage count so that they could be cleared if necessay. Buffers written by this process increment the
Writing dirty buffers on backend request may cause a delay of the response to the client request. Using the clean writer process may mitigate this effect. Writing least recently used pages (which have a low usage count) is enabled if
bgwriter_lru_maxpages has a value bigger than 0. The number of pages to be written is calculated via the number of recently allocated buffers (you can see it in
buffers_alloc) multiplied by
bgwriter_lru_multiplier (which defaults to 2).
So a higher allocation rate may lead to a higher amount of buffers clean operations. These cause a higher I/O between checkpoints caused by background writer. On the other hand the higher allocation rate results in a lower cache hit ratio. This may a have serious impact on client applications e.g. it could cause canceling of querys with a very short query timeout. The shared buffer cache should be increased.
On a healthy system there should >90% of all checkpoints triggered by time. Based on a history of entries of
pg_stat_bgwriter view this can easily verified by comparing the calculated checkpoint interval with current setting. Furthermore buffers written on checkpoint should be higher than 80% of the this total number of blocks written. The total number of blocks written is the sum of
- buffer written on checkpoint
- buffers written on clean
- buffer written on backend request
So the ratio of cleaned buffers should be small while the ratio of buffers written by a regular checkpoint should be higher.
The statistics view pg_stat_bgwriter provides you the current state of statistics.
You can reset the statistic:
If you want to make analysis on background writer statistics you either have to reset the statistics or collect data into into a log table. From these values important indicators of database state can be calculated and can give hints which setting of the PostgreSQL cluster has to be adjusted.
Interesting further reading:
- Gregory Smith (2010): PostgreSQL 9.0 High Performance. by Packt Publishing Ltd.
